Products Details

Item#:	902142-T
Name:	I2C Relay Out 8 Module w/Terminal
Weight:	0.1 lbs
LeadTime:	10 Days
Price(USD): ea
Qty 1 - 19	$115.44
Qty 20 - 99	$109.03
Qty 100 - 499	$102.61
Qty 500 - 999	$96.20
Qty 1000+	$89.78
Qty

Click on Image for larger view

Description:
I2C Relay Out 8 Module w/Screw Terminal Connectors
This boards can control 8 relays. Each relay can switch 2A at 125V.
Relays are control from either the P0 or P1 Interface GPIO pins.
Relay Max current: 2A at 30VDC, 0.6A 125VAC, 0.6A at 110VDC.
Includes: Mount Hardware
Dimensions: 4"x2.75" (101.6mm x 69.85mm)

Relay Module DataSheet
Relay Module Schematic
Relay Module PCB
