New Products at Delcom.

706601 USB HID Programmable Single Button Arcade Switch w/2M Cable
USB HID Programmable Single Button Arcade Switch with 2M Cable.
This device can be programmed to emulate keycodes, mouse buttons and joystick buttons .
See the 890672 Delcom Setup Utility below to setup the device.
Device also supports the FootCtrl, DelcomDLL and all generation 2 commands(Button connected to pin P0.0 and LED on P1.4).
Supports all Major operating systems (32 and 64 bit). Simple plug and play USB compliant device. Uses the systems USB HID driver, no drivers to load. Unique serial number in each device, for use with multiply devices.
Self Powered from the USB port. Die Cast Aluminum Enclosure.
Dimensions are 1.98" x 1.98" 1.235" (50.5mm x 50.5mm x x 31.5mm).
Includes 2 Meter USB Cable.

Available with RED, CLEAR, YELLOW or BLUE lighted button. Default color is RED. For other colors, note the color on check out page 4 in the USER NOTES box.

703221 USB Joystick 2 Axis 1 Button
USB Joystick with X and Y axis and center button.
Device can work in two modes, HID Mode where it looks like a game joystick via the game port. Or can be read using your software for custom applications. See the Delcom Setup Utility for setup.
Type: Panel mount. Cutout dimension: 39.7mm (1.562").

Also available in a 3 axis and with enclosure. Contact factory for more details.
Circuit board can support four optional outlet, such as LEDs.

990601 USB HID G3 ADC C++ MFC Example Code
USB HID G3 Analog to digital converter example code in MFC C++.
HIDIOG3ADC.exe
HIDIOG3ADC.zip

990602 USB HID G3 Event Counter C++ MFC Example Code
USB HID G3 Event Counter example code in MFC C++.
HIDIOG3EC.exe
HIDIOG3EC.zip

900204 USB HID Quad Relay/Opto Module
USB HID Quad Relay output and Quad Optoisolator input module.
This boards controls 4 relays and 4 input optoisolators.
Each relay as 3 connections (NO, C, NC).
Each relay can switch 2A at 30VDC and 0.6A at 125VAC.
Relay mapping:
P1.4 -> Relay1, P1.5 -> Relay2, P1.6 -> Relay3, P1.7 -> Relay4 (Relays active low)
Optocoupler inputs are tied to P0.0-3 and are active from 2 to 60 volts.
The Optocoupler part number used is TOSHIBA TLP293-4(GB,E

Powered and controller via the USB port.
Dimensions: 2.5"x2.0"
Schematic
PCB

890632 USB HID MFC VB.NET Example
USB HID VB.NET Visual Basic Application & Source Code.
Built on Visual Studio 2012 with ASP.NET v4.5.
This example program works with all our USB HID products.
This examples communicates directly to the USB HID Driver.
Show how to register for USB Device ADD/REMOVE Messages.


890610 USB HID G2 Linux Example Code3
DelcomLinux - A simple Linux example using the libhid lib to read and write the Delcom USB Device. Works with all Delcom HID device (Generations 2,3+). Tested on Ubuntu V14

Download Source Code

706562 USB HID Programable Dual Anti-Vandal Switch w/2M Cable
USB HID Programable Dual Anti-Vandal Switch with 2M Cable.
This device can be programmed to emulate keycodes, mouse buttons and joystick buttons .
See the 890672 Delcom Setup Utility below to setup the device.
Device also supports the FootCtrl, DelcomDLL and all generation 2 commands (Button connected to pin P0.0, P0.1 and LED on P1.4 and P1.5)
Supports all Major operating systems (32 and 64 bit). Simple plug and play USB compliant device. Uses the systems USB HID driver, no drivers to load.
Unique serial number in each device, for use with multiply devices.
Self Powered from the USB port. Die Cast Aluminum Enclosure.
Dimensions are 3.8" x 1.5" 1.2".
Includes 2 Meter USB Cable.

Available with RED, GREEN OR BLUE back lighted button. Default color is RED. For other colors, note the color on check out page 4 in the USER NOTES box.

902252-SOIC28 USB HID FS 19 GPIO CHIP SOIC28
Preprogrammed USB Full Speed HID Chip 19 GPIO
Based on the Microchip PIC18F2550 USB chip.
Package: 28-SOIC (??", ??mm Width)
19 programmable Input/Output pins.
Minimum external required parts; USB Chip, Crystal, Resistor and Caps.
Features; I2C Port, Event counter, 1 and 8 byte buffered data mode with handshaking, 64 Bit I/O Command, Clock generator with variable duty cycle, Variable current sink control. Self powered from the USB Cable. Up to 450mA available to the user. Unique serial number in each chip.
Uses the built in HID driver.
Chip Data Sheet
Basic Schematic


902251-SSOP20 USB HID FS 14 GPIO CHIP SSOP20
Preprogrammed USB Full Speed HID Chip 14 GPIO
Based on the Microchip PIC18F14K50 USB chip.
Package: 20-SOIC (0.295", 7.50mm Width)
14 programmable Input/Output pins.
Minimum external required parts; USB Chip, Crystal, Resistor and Caps.
Features; I2C Port, Event counter, 1 and 8 byte buffered data mode with handshaking, 64 Bit I/O Command, Clock generator with variable duty cycle, Variable current sink control. Self powered from the USB Cable. Up to 450mA available to the user. Unique serial number in each chip.
Uses the built in HID driver.
Chip Data Sheet
Basic Schematic


Node.js Delcom USB HID Visual Signal Indicator
Node.js library for USB HID Visual Signal Indicator (Gen2) Tested on Windows, Linux (including Raspian for Raspberry Pi) and Mac.
