Item#: 906009
Name: USB HID 8 Digit Numeric Display - Green
Weight: 0.16 lbs
LeadTime: 2-4 Days
Price(USD): ea
    Qty 1 - 19$71.42
    Qty 20 - 99$69.12
    Qty 100 - 499$66.82
    Qty 500 - 999$64.52
    Qty 1000+ $61.06
Qty

Click on Image for larger view

Description:
The USBNDSPY is a Green 8 digit USB HID 7 Segment LED Displays. The device is self powered and controlled via the USB port. Data can be entered in three modes; raw, hex and ascii. Device has programmable flash rate and optional piezo buzzer is available. Simple plug and play technology. Digit height is 0.560". PCB dimensions are 3" by 1.5". Available with or with out enclosure. Includes 2 Meter USB Cable. Unique serial number in each device.
LED color: GREEN
Extra Image
Applications: Instrumentation, WebSite Counters, POS, Equipment, Process Counters.


DECLARATION OF CONFORMITY
DATASHEET
USB HID G2 Datasheet USB HID G2 Datasheet. Datasheet for all the Delcom USB HID products.
SOFTWARE
890514 USB HID Numeric Display Test Program
Delcom DLL Delcom DLL files and manual. The Delcom DLL allows simple integration between the Delcom USB devices and users programs. Works with C/C++, VB, Delphi, Labview, Labwindows and others.
