Description: USB HID Programmable Round Toggle ON-OFF-MOM Switch with 2M Cable.
This device can be programmed to emulate keycodes, mouse buttons and joystick buttons .
See the 890672 Delcom Setup Utility below to setup the device.
Supports all Windows, MAC and linux operating systems.
Simple plug and play USB compliant device, which uses the standard USB HID driver.
Unique serial number in each device, for use with multiply devices.
Self Powered from the USB port. Die Cast Aluminum Enclosure.
Dimensions are 1.98" x 1.98" 1.235" (50.5mm x 50.5mm x x 31.5mm).
Includes 2 Meter USB Cable.
Toggle switch has ON-OFF-MOMENTARY positions.
Push the toggle switch up (event on P0.1), towards the USB cable, for the momentary function.
Pull the toggle switch down (event on P0.0), alway from the USB cable, for the latching ON state.
Center position is the OFF position.
Applications: Process Equipment, Automated Processes, Medical Equipment, Gaming, Special needs
DECLARATION OF CONFORMITY
|
890672 | Delcom Setup Utility | |
900000 | Delcom GEN2 USB HID Examples and Documentation |
|
